Charger 900W-18A for 36V Lithium Iron Phosphate LiFe (LiFePO4) battery
The 900W-18A charger for 36V Lithium Iron Phosphate battery optimizes the performance and lifespan of Lithium batteries. This product is designed for charging 3 x PowerBrick® 12V in series (36V)
The charger has electrically isolated DC output allowing mulitple chargers to be connected in parallel or/and in series to increase the charging power and shorten the charging time.With energy efficiency > 85%, the charger produces less heat, delivers more energy and allows faster charging.
This charger 36V 900W-18A for Lithium Iron Phosphate battery incorporates a charging algorithm optimized for LiFePO4 technology batteries.
Charge curve is CC-CV type : Constant current (CC) / Constant voltage (CV) with end of the charge trigered with current output < 100mA. The LFP (LiFePO4) technology allows a fast charging of the battery, sometimes < 2 hours.
Lithium technology has a very low discharge (<3% per month), the floating function is not useful. Moreover, it is necessary for the lithium cells to relax after the end of charging, so floating is not recommended.
Charging current is automatically regulated thanks to its algorithm for more efficient charging and longer battery lifespan.
It is protected against short-circuit and accidental polarity reversal. The metal case is equipped with active ventilation system allows the charger to be used in harsh environments or hot climates.
- Front panel LEDs: LED 1 RED (power supply), LED 2 RED (charging), LED 2 GREEN (complete charging)
- Electrical protection: Short-circuit, reverse polarity, overvoltage
- Integrated ventilation system
- Power supply 230VAC-50/60Hz
